High Temperature Resistant Powder Coatings

The series of products are thermosetting powder coatings designed and produced with special materials to have excellent heat resistance properties.

Heat Resistance

650F / 1 Hour

The series of products are thermosetting powder coatings designed and produced with special materials to have excellent heat resistance properties.

Heat Resistance

650F / 1 Hour

Powder Properties

· Specific gravity: 1.2~1.8 g/cm³

· Particle size: average particle diameter generally 30~38 µm, with >99% of particles <66 µm. Please specify any special requirements in advance.

· Flowability: Exhibits good fluidization and transport properties; fluidization index available upon request from the company.

· Storage stability: Can be stored at <25°C for up to one year.

· Specific gravity: 1.2~1.8 g/cm³

· Particle size: average particle diameter generally 30~38 µm, with >99% of particles <66 µm. Please specify any special requirements in advance.

· Flowability: Exhibits good fluidization and transport properties; fluidization index available upon request from the company.

· Storage stability: Can be stored at <25°C for up to one year.

Coating Performance

Appearance

Visual inspection

Multiple surface effects

Acid

resistance

5%H₂SO₄

1 Year

Color stability, Blister resistance.

48%HCL

1 Month

5%HAC

1 Year

5%H₃PO₄

1 Year

Alkali

resistance

5%NaOH

30 Days

5%NaCO₃

Appearance

Visual inspection

Multiple surface effects

Solvent

resistance

Acetone

Brush

50 times.

Color stability, Blister resistance.

Xylene

Methyl ethyl ketone (MEK)

Gasoline

Alcohol

Ethyl acetate

Particle Size Distribution Graph

Appearance

Visual inspection

Multiple surface effects

Pinhole thickness

Pinholes are likely to occur when the coating thickness exceeds 150μm. Please notify in advance if the required coating thickness is greater than 150μm.

Salt spray resistance

GB1771-91

1000H

No change in the coating, corrosion at the cross-cut area is less than 2mm on one side. This test was conducted using chromated aluminum panels with a coating thickness of 100μm.

Humidity resistance

GB1740-79

1000H

Slight loss of gloss in the coating, less than Grade 1.

Light aging resistance

Good

Application Conditions

● Pre-treatment

Steel Phosphating Aluminum profile Chromating

Note: Pretreatment inspection should be conducted every 4 hours. The inspection method should follow the requirements of the chemical supplier or the company's pretreatment instructions.

Steel Phosphating Aluminum profile Chromating

Note: Pretreatment inspection should be conducted every 4 hours. The inspection method should follow the requirements of the chemical supplier or the company's pretreatment instructions.

Steel Phosphating Aluminum profile Chromating

Note: Pretreatment inspection should be conducted every 4 hours. The inspection method should follow the requirements of the chemical supplier or the company's pretreatment instructions.

● Coating Application

This product series is suitable for the following application methods:

· Corona electrostatic spray

· Tribo electrostatic spray

· Electrostatic fluidized bed coating (prior request required)

· Fluidized bed dip coating (prior request required)

· Other coating methods (prior request required)

· Corona electrostatic spray

· Tribo electrostatic spray

· Electrostatic fluidized bed coating (prior request required)

· Fluidized bed dip coating (prior request required)

· Other coating methods (prior request required)

Note: Coating quality inspection should be performed at least every 2 hours. The inspection method should follow customer requirements and the company's film testing procedures.

● Curing Conditions

This product series is suitable for the following curing methods:

· Electric heating

· Radiation heating

· Infrared heating

· Oil or gas-fired heating (prior consultation recommended).

· Electric heating

· Radiation heating

· Infrared heating

· Oil or gas-fired heating (prior consultation recommended).

· Electric heating

· Radiation heating

· Infrared heating

· Oil or gas-fired heating (prior consultation recommended).

Note: Regularly check oven temperature, once per week.

Additional

● Application Areas

Cookware, instrument and meter housings, electromechanical equipment, and other applications requiring high-temperature resistance.

● Special effects

Various textures, metallic finishes, pearlescent effects, and mixed colors. For the use of special surface effect coatings, please refer to the company's usage guidelines.

● Packaging and transportation

25kg cardboard boxes lined with polyethylene plastic bags. Non-hazardous goods, can be transported by various methods. Avoid direct sunlight, moisture, heat, and contact with chemicals.

● Health and safety

Please refer to the company's safety, health, and environmental operation guidelines, and request the "Safety Technical Report" from the company.
